3 -26
Roll-bar
540E PTO switch
(13) 540E PTO switch (Roll-bar
type, If fitted)
It is used to turn on/off the 540E PTO operation
mode when working in the field.
In this mode, the engine maximum speed will be
restricted up to the designated engine speed
related to the 540 PTO speed for economic PTO
operation.
When the PTO gear lever is in 750/540E rpm
position and the PTO switch is turned on, if
pressing this switch to “ON” position, the 540E
PTO mode is ready.
ON - press the upper side (symbol part) of the
switch.
OFF - press the lower side of the switch.
▶ If placing the PTO switch or 540E PTO switch to “OFF” position or placing the PTO
gear lever to other position except 750/540E position while the engine maximum
speed is restricted, The 540E PTO mode may be exited and the engine speed can
be suddenly increased.
▶ Before exiting the 540E PTO mode, lower the engine speed to idle rpm.
Caution
