LS tractor XP8084 - Page 129

3 -59
SPN FMI Relating Part(s) Description
110200
01
System oil pressure
sensor
TM oil pressure range is less.
04 TM oil pressure sensor is cut-off.
03 TM oil pressure sensor is shorted.
120100
04
Forward/Reverse
synchro position sensor
F/R synchro position sensor is cut-off.
03 F/R synchro position sensor is shorted.
11 F/R synchro calibration is omitted.
13 F/R synchro calibration range is over.
07 F/R synchro movement error.
120200
04
1458 synchro position
sensor
1458 synchro position sensor is cut-off.
03 1458 synchro position sensor is shorted.
11 1458 synchro calibration is omitted.
13 1458 synchro calibration range is over.
07 1458 synchro movement error.
120500
05
Forward/Reverse motor
F/R motor is cut-off.
06 F/R motor is shorted.
15 F/R motor current overflow.
120600
05
1458 motor
1458 motor is cut-off.
06 1458 motor is shorted.
15 1458 motor current overflow.
121100
05
C1 valve
C1 valve is cut-off.
06 C1 valve is shorted.
15 C1 valve current overflow.
121200
05
C2 valve
C2 valve is cut-off.
06 C2 valve is shorted.
15 C2 valve current overflow.
121300
05
C3 valve
C3 valve is cut-off.
06 C3 valve is shorted.
15 C3 valve current overflow.
121400
05
C4 valve
C4 valve is cut-off.
06 C4 valve is shorted.
15 C4 valve current overflow.
