Lucent Technologies DDM-2000 OC-12 - Page 34

Tables
Issue 1 December 1997 xxxv
3 Shelf Descriptions and Configurations
3-1 DDM-2000 OC-12 Plug-Ins 3-4
3-2 DDM-2000 OC-12 Multiplexer Circuit Pack and
Software Compatibility Matrix 3-8
3-3 DDM-2000 Fan Shelf Switch Settings 3-20
5 Transmission and Synchronization Interfaces
5-1 DDM-2000 OC-12 Multiplexer Application
Summary Matrix 5-2
5-2 DDM-2000 OC-12 Multiplexer Synchronization 5-14
5-3 Synchronization Messages using K2 Byte 5-21
5-4 Synchronization Messages using S1 Byte 5-22
5-5 Available Synchronization References 5-23
6 Operations Interfaces
6-1 Craft Interface Terminals 6-3
6-2 DDM-2000 OC-12 Pushbutton Combinations 6-11
8 Administration and Provisioning
8-1 OI Software Compatibility 8-11
8-2 DDM-2000 OC-12 Manual STS-1 Cross-
Connections (Termination). 8-17
8-3 DDM-2000 OC-12 Manual STS-3c Cross-
Connections (Termination). 8-17
8-4 DDM-2000 OC-12 Manual STS-1 Cross-
Connections (Rings Pass-Through) 8-18
