RadioRA® Setup Guide
Programming Preparations
1-8
Step 3 Complete ROOM/SCENE
assignment
Simultaneously press and hold the 3rd, 5th,
and ALL OFF buttons in the right most column
until the LEDs stop flashing (approximately 3
seconds).
Note: On a 5 button Raise/Lower Wall Master,
press and hold the 3rd, 5th, and Lower
buttons.
Step 4 Label columns
Apply the supplied ROOMS or SCENES labels
to the space provided over each button
column.
SCENES ROOMS ROOMS
Step 2 Changing ROOM/SCENE
assignments
Press the 1st button in a column to make that
column a ROOM column, or press the 2nd
button to make it a SCENE column.
ALL OFF
ALL ON
ROOMSSCENES
• Proceed to Assigning Dimmers,
Switches or GRAFIK Eye® Control Units
to ROOM Buttons on page 1-9.
Section 1 - Start-Up
Shown: Setting
left most column
as SCENES.
