RadioRA® Setup Guide2-1
Advanced Programming
Section 2 - Advanced Features
Step 1 Begin the ALL ON button
programming
Programming the ALL ON Button
The ALL ON button on a RadioRA® Master Control will, by default, turn ON all Dimmers and Switches to full
intensity, and GRAFIK Eye
® Control Units to Scene 1 when pressed. The ALL ON button can be programmed to
turn ON selected Dimmers (to full intensity), Switches, or GRAFIK Eye Control Units (to Scene 1).
Step 2 Press the ALL ON button
On the Master Control you want to program,
simultaneously press and hold the 2nd and 4th
buttons in the right most column until the
upper right LED begins to flash (approximately
3 seconds).
Press the ALL ON button on the Master
Control you are programming.
Upper right LED flashes.
Tabletop Master Wall Master
OR
The LEDs in all columns will simultaneously
cycle from bottom to top.
LEDs cycle UP
All Dimming/Switching Controls and GRAFIK
Eye® Control Units will turn ON.
ALL ON
ALL OFF
These programming steps only apply to Master
Controls equipped with an ALL ON button.
