Lynx NGT-9000s
Installation Manual
A.2.11 I
2
C Serial Bus (Detachable Configuration Module)
The I
2
C serial bus is used to communicate with the Detachable Configuration Module to store the
following configuration options:
1. Configuration module Config Version
2. Configuration module Configuration Data CRC
3. Installation Calibration Parameters (non-box specific)
• Audio Volume Level
•
TAS Antenna Calibration and Serial Number
4. Aircraft Specific Configuration Options
• Aircraft Tail Number
• Mode S Identifier
• Transponder Diversity Enable
• TAS Enable
• TAS Extended Callout Enable
• TAS Directional Antenna Type
• Antenna Installation
• TAS Directional Antenna Type
• Aircraft Emitter Category Type Code
• Broadcast Category
• Pilot Entry of Flight ID
• Aircraft Length and Width Code
• Aircraft Maximum Airspeed
• Normal Traffic Color
5. AHRS and Altitude Configuration Options
• AHRS Source
• AHRS ARINC 429 Bus Speed
• Altitude Source
• RS-232 Altitude Protocol
• RS-232 Altitude Baud Rate
• ARINC 429 Altitude Bus Speed
• Resolution
6. Misc Configuration Options
• ARINC Input #1
• ARINC Input #2
• ARINC Output #1
• RS-422 Baud Rate
• RS-422 ADS-B Output
• RS-422 FIS-B Weather Output
• CDTI Output
• Control Panel Type
• In Air /On Ground - On Ground Discrete Installed
• In Air /On Ground – Ground Speed Threshold
• In Air /On Ground - Altitude Threshold
A.2.12 Antenna Connections
The unit has 5 TNC connections labeled A1 thru A5. All models of the Lynx NGT-9000s are required to
have GPS and Omnidirectional (UAT) cable connections (A5 & A4). Models with TAS have three cables
connecting to A1, A2, and A4. Models with Diversity have one cable connecting to A2.
0040-17001-01 Appendix A Page A-7
Revision A January 15, 2015
