Lynx NGT-9000s
Installation Manual
1.7.1 TSO Markings
The following information summarizes the TSO application for the NGT-9000D Release 1 and DCM
Release 1.
Table 1-6: TSO Markings
TSO No. TSO MARKING TSO TITLE
C112d Level 2 dens Class 1 Air Traffic Control Radar Beacon System/Mode Select
(ATCRBS/Mode S) Airborne Equipment
C113a Airborne Multipurpose Electronic Displays SAE
AS8034B, Multipurpose Display
C145c Class Beta 1 Airborne Navigation Sensors Using The Global
Positioning System Augmented By The Satellite Based
Augmentation System
C147 Class A Traffic Advisory System (TAS) Airborne Equipment, DO-
197A, Traffic Advisory System
C154c Class A1S Receive Only Universal Access Transceiver (UAT) Automatic
Dependent Surveillance- Broadcast (ADS-B) Equipment
Operating on Frequency of 978 MHz
C157a Class 2 Aircraft Flight Information Services-Broadcast (FIS-B)
Data Link Systems and Equipment
C166b Class A2 Extended Squitter Automatic Dependent Surveillance -
Broadcast (ADS-B) and Traffic Information Service –
Broadcast (TIS-B) Equipment Operating on the Radio
Frequency of 1090 Megahertz (MHz)
C195a Class B1, B5, C1, C5 Avionics Supporting Automatic Dependent Surveillance –
Broadcast (ADS-B) Aircraft Surveillance Applications
(ASA)
Page 1-16 General Information 0040-17001-01
January 15, 2015 Revision A
