Lynx NGT-9000s
Installation Manual
1.10.1 Installation Kits
Ordering Installation Kits is a customer option. Refer to the following for ordering information:
Table 1-12: Installation Kit P/N 9060-17000-01 for Straight RF Connector
DESCRIPTION
PART NUMBER
QTY
Cable Tie 4.1x0.098 NYL 6.6 Black Low Pro PBF
1040-10002-01
15
Screw F100 2-56 X 0.250 SS Pass W/ Vibra-Tite
2000-10085-01
8
Screw 4-40 X 0.312 SS Pass W/ Vibra-Tite
2000-10087-01
10
Contact D-Sub Combo 50 Ohm Plug solder/Crimp
3050-10124-01
5
Rack Rear Plate Panel Mount
9000-17025-02
1
Floating Nut Plate D-Sub Shell Size 5
9000-17034-01
1
Enclosed Backshell Shell Size 5
9000-17035-01
1
Floating Nut Plate D-Sub Shell Size 3
9000-17036-01
1
Screw, Machine
MS35206-230
6
Wire Clamp
9000-17076-01
2
Float RF backshell 5W5 d-sub shell size 3
9000-17106-01
1
Shield Clamp .55 Mounting Center
9010-17012-01
1
Panel Mount Rack Assembly
9010-17022-01
1
Cable Ground Strap
9020-17002-01
2
Connector D-Sub 78 Position Float Mount Assembly
9080-17006-01
1
Connector D-Sub 5 Position 5W5 Float Mount Assembly
9080-17007-01
1
Contact Socket Crimp Size 22D
M39029/57-354
78
Screw, F100 4-40 x 0.312
NAS514-P-440-5
4
Screw, F100 4-40 x 0.438
NAS514-P-440-7
4
Grounding Clip Copper Spring With Ground Finger Stock
9001963-001
1
Wire Clamp Pad
9000-17132-01
2
Table 1-13: Installation Kit P/N 9060-17000-02 for Right Angle RF Connector
DESCRIPTION
PART NUMBER
QTY
Screw, 4-40 x 0.188 with Vibra-Tite
101-10114-011
2
Cable Tie 4.1x0.098 NYL 6.6 Black Low Pro PBF
1040-10002-01
15
Screw F100 2-56 X 0.250 SS Pass W/ Vibra-Tite
2000-10085-01
8
Screw 4-40 X 0.312 SS Pass W/ Vibra-Tite
2000-10087-01
8
Contact D-Sub Combo 50 Ohm Plug solder/Crimp
3050-10123-01
5
Rack Rear Plate Panel Mount
9000-17025-02
1
Floating Nut Plate D-Sub Shell Size 5
9000-17034-01
1
Floating Nut Plate D-Sub Shell Size 3
9000-17036-01
1
Wire Clamp
9000-17076-01
2
Float RF Backshell 5W5 D-Sub Shell Size 3 90deg Right Angle
9000-17105-01
1
Wire Clamp Pad
9000-17132-01
2
Grounding Clip Copper Spring With Ground Finger Stock
9001963-001
1
Enclosed Backshell, Shell Size 5
9010-17012-01
1
Panel Mount Rack Assembly
9010-17022-01
1
Cable Ground Strap
9020-17002-01
2
Connector D-Sub 78 Position Float Mount Assembly
9080-17006-01
1
Connector D-Sub 5 Position 5W5 Float Mount Assembly
9080-17007-01
1
Contact Socket Crimp Size 22D
M39029/57-354
78
Screw, Machine
MS35206-230
6
Screw, F100 4-40 x 0.312
NAS514-P-440-5
4
Screw, F100 4-40 x 0.438
NAS514-P-440-7
4
Page 1-24 General Information 0040-17001-01
January 15, 2015 Revision A
