Lynx NGT-9000s
Installation Manual
1.5 INSTALLATION CONSIDERATIONS
The installation of the following equipment is the minimum required by the Unit to provide ADS-B
functionality as well as the optional TAS and Diversity functionality.
• Each installation requires at a minimum the following equipment installed:
1. Lynx NGT-9000s
2. Detachable configuration module
3. GPS Antenna
4. L-Band (978/1030/1090 MHz) Antenna
5. Altitude Source (ARINC 429, RS-232, or Gilham Code)
• A Unit with TAS (model: NGT-9000+) also requires the following:
1. Unlock code to unlock TAS option via the Lynx MAT
2. Directional Antenna (NY156 or NY164)
• A Unit with Diversity (model: NGT-9000D) also requires the following:
1. Unlock code to unlock Diversity option via the Lynx MAT
2. Additional L-Band Antenna, located on the top of the aircraft.
0040-17001-01 General Information Page 1-11
Revision A January 15, 2015
