Lynx NGT-9000s
Installation Manual
4.7 DISPOSITION OF FAILED ITEMS
1. The Lynx NGT-9000s can only be repaired by a FAA Certified Repair Station Facility.
2. The configuration module, NY156, and NY164 cannot be repaired and must be replaced.
3. Return defective components to:
L-3 Avionics Systems
Attn: Field Service
5353 52nd Street, S.E.
Grand Rapids, MI USA 49512-9704
4. Refer to the manufactures data for external displays, controllers, and antennas interfaced to the Lynx
NGT-9000s.
5. If available, pack components in their original shipping container. If the original container is not
available, pack them as follows:
CAUTION
Do not use desiccant crystals when packaging electronic assemblies.
Since the assembly must be packed tightly, crystals in bag form cannot
be used. The use of loose crystals may cause unnecessary damage
resulting in a cleaning problem.
a. Ensure that conductive covers/caps are installed on the exposed terminals of connector, if
applicable.
b. LRU's that are marked as electrostatic discharge sensitive (ESDS) must be wrapped in static
protective materials.
c. Wrap with bubble pack. Secure bubble pack with reinforced tape.
d. Place assembly in a cardboard box.
e. Wrap any accessories in tissue and place in the box. Fill spaces with bubble pack.
f. Place an explanation letter in the box with the following information.
• Your name, address, and telephone number.
• Purchase order number.
• Description of component including, when applicable, model and serial number.
• A brief description of the difficulty.
g. Shut box, and seal with reinforced tape.
h. Attach packing list to outside of box.
Page 4-32 Maintenance 0040-17001-01
January 15, 2015 Revision A
