Lynx NGT-9000s
Installation Manual
1.11.3 Directional Antenna
The antenna listed in Table 1-19 have been tested for compatibility. Antennas not listed below can still be
approved for installation but must meet the specifications for Directional antenna that support TCAS or
TAS operation and meet the specifications required by the Lynx NGT-9000+.
NOTE
The NY156 and NY164 Directional Antenna may not be used for non-TAS functions.
To fit specific airframes, a special adapter plate is also required. The adapter plate is included in the
installation kit shipped with each system. Table 1-20 lists the contents of each installation kit. The
installation kits differ only in the size of the special airframe adapter plate.
Table 1-21 lists of installation kits associated with various airframes. For aircraft not listed, contact the
aircraft manufacturer for information relative to the radius of the area where the antenna is to be mounted.
Table 1-19: Directional Antenna Model Options and Specifications
PART NUMBER:
• 805-10003-001 (NY156 - White Paint).
Used for Installations with TCAS1 or TAS.
• 805-10890-001 (NY164 - White Paint).
Used for Installations with TAS.
• 805-10890-002 (NY164 - Black Paint).
Used for Installations with TAS.
MANUFACTURER
L-3 Avionics Systems
CERTIFICATION:
TSO-C118 and TSOC147
RTCA COMPLIANCE:
DO-160C (For further details refer to Appendix B - Environmental
Qualification Form.)
SIZE:
1.3 inches (3.25 cm) high
6.23 in (15.82 cm) wide
11.12 in (27.94 cm) deep
WEIGHT:
2.3 lb (1.04 kg)
SPEED:
Rated to 600 knots (0.9 Mach) @ 25,000 feet.
FREQUENCY:
1030-1090 MHz
FINISH:
Gloss white or black Skydrol resistant polyurethane paint.
OPERATING TEMPERATURE:
-55° to +70°C (-67° to +185°F)
STORAGE TEMPERATURE:
-55° to +85°C (-67° to +185°F)
MAXIMUM ALTITUDE:
55,000 ft (installation environment)
SCHEDULED MAINTENENACE:
None.
SERVICE LIFE:
Unlimited.
REPAIRABILITY:
Replacement only.
0040-17001-01 General Information Page 1-29
Revision A January 15, 2015
