Lynx NGT-9000 User Manual

Lynx NGT-9000s
Installation Manual
Table 1-20: Directional Antenna Installation Kit 817-10009-xxx
KIT PART
NUMBER
SUPPLIED PARTS *
PART NUMBER
DESCRIPTION
QUANTITY
817-10009-001 800-10066-001 Special Adapter Plate, 40 Inch (101.6 cm) Radius 1
817-10009-002 800-10066-002 Special Adapter Plate, 63 Inch (160.0 cm) Radius 1
817-10009-003 800-10066-004 Special Adapter Plate, 80 Inch (203.2 cm) Radius 1
817-10009-004 800-10066-003 Special Adapter Plate, 32 Inch (81.3 cm) Radius 1
817-10009-005 800-10066-005 Special Adapter Plate, 47 Inch (119.4 cm) Radius 1
817-10009-006
(No Adapter Plate)
100-10022-001*
101-10027-001*
Screw, 10-32 x 1 PPH SS (MS51958-67)
Stop Nut, 10-32 (MS21044C3)
4
4
* Hardware supplied with all kits.
Table 1-21: Airframe Installation Kits
MANUFACTURER AIRFRAME INSTALLATION KIT P/N
Cessna CITATION III, VI, VII
CITATIONJET, CITATION I, II, V
182, 210, 337, 401, 414, 425, 441
817-10009-001
817-10009-004
817-10009-006
MOONEY M20 817-10009-006
Page 1-30 General Information 0040-17001-01
January 15, 2015 Revision A
