Lynx NGT-9000 User Manual

Lynx NGT-9000
Installation Manual
3.4 MAINTENANCE MODE
The unit can enter Maintenance mode without the use of a MPC using the following procedure.
NOTE
If the unit has detected that it is in-air, then maintenance mode can only
be entered in the first two minutes of operation.
1. Apply power to the unit as indicated in paragraph 3.2.1.
2. With the splash screen showing press and hold (continue holding when the status and version screens
are showing) in the lower left corner of the display until the Activate Maintenance Mode window is
shown on the right screen. See Figure 3-5.
Figure 3-5: Activate Maintenance Mode Window
3. Tap the Yes button to restart the unit in Maintenance Mode. Note - Tapping the No screen button or
10 seconds of inactivity starts normal operation mode. The Maintenance Mode windows are shown
in Figure 3-6.
• Note: Some failure conditions automatically activate the maintenance mode. The reason for the
automatic activation is shown on the screen.
Main Screen Reboot Screen
Figure 3-6: Maintenance Mode Screens
4. From the Main Screen tap the Reboot text.
5. From the Reboot menu tap the Maint No-WiFi >.
• A maintenance screen is shown on the unit while in maintenance mode.
Page 3-6 Installation Checkout 0040-17001-01
January 15, 2015 Revision A
