Lynx NGT-9000s
Installation Manual
1.3.3 System Unlock Code
Unlock codes are required if installing and activating the TAS and Diversity options. The unlock codes
are 10 digit codes that are entered during installation using the Lynx MAT to install either of these
options. The unlock codes may be purchased and shipped with the unit. If the unlock code is not included,
contact L-3 Avionics Systems Customer Service to obtain the code. Be sure to have the Mode-S ID (e.g.
ICAO) available for the service representative. The unlock code is associated with the aircraft ICAO
address and will only work for that aircraft ID.
1.4 INTERFACES
The unit supports a number of built-in interfaces as described in Table 1-2. A system block diagram is
provided in Figure 1-3. Additional information on these interfaces is detailed below. Refer to Appendix A
for interface options and the installation section for an interconnect diagram.
Table 1-2: Built-in Interfaces
Interface (No.) Function
ARINC 429 Input (4) Receive ADC and AHRS data
ARINC 429 Output (1) Transmit to a traffic display
Discrete Inputs (17) Receive Gillham Altitude Encoder, Audio Mute, IDENT
Command, and In Air / On Ground (WOW) status
Discrete Output (9) Transmit ADS-B Out Fail, TIS-B Out of Coverage, Traffic Alert
output
RS-232 Input / Output (4) Wi-Fi accessory port
RS-232 Input (1) Altitude Encoder port
RS-422 Input / Output (1) External display port
RF Suppression Input / Output (1) Provides on aircraft suppression of the L-band equipment
Analog Audio Output (1) Connects to Audio Panel un-muted input.
I2C Port (1) Detachable configuration module
GPS Antenna Port Connect to a top mount antenna providing GPS data to support
ADS-B functionality
L-Band Antenna Port Connects to the bottom mount antenna. Provides UAT 978
MHz input, 1030/1090 MHz extended squitter input/output to
support ADS-B/ATAC Transponder functionality.
Extra Antenna Ports Connects to a top mounted antenna (L-Band or Directional)
providing optional TAS or Diversity functionality.
Note: Not all interfaces are used. Some are spares, reserved for future use, or optional.
0040-17001-01 General Information Page 1-7
Revision A January 15, 2015
