Lynx NGT-9000s
Installation Manual
2.3.1 Location
The unit is mounted in the instrument panel where the touch screen display can be used to view aircraft
flight information and provide operational control.
1. The unit should be accessible for inspection, maintenance, or removal, and free from instrument
panel structural flexure and excessive vibration or heat.
2. The wiring and antenna cables should not run adjacent to heaters, engine exhaust, or heat sources.
3. The display viewing envelope has a viewing angle of at least ±45° in the horizontal plane and at least -
10º to +30º in the vertical plane as seen from an eye position of 30 inches from the front of the display.
4. The unit should be located in an area where the touch screen control is within easy reach of the pilot
and cannot be obstructed from continuous view (i.e. behind a control yoke).
5. A Mounting Rack is required to install the panel mount NGT-9000. Two installation kits are
available each with their own mounting rack. See details below:
• Mounting Rack Assembly with Straight RF Connector P/N 9060-17000-01
• Mounting Rack Assembly with Right Angle RF Connector P/N 9060-17000-02
Ordering information for the installation kits are found in the General Information section.
6. Compare the space requirements of the Mounting Rack with the installation area being considered.
The outline drawing for the unit is located in Figure 2-1. The outline drawing of the Rack Assembly
is located in Figure 2-2. The installer is advised to consider the space requirements (2-3 inches)
needed for the connector backshell and the cable bend radius.
0040-17001-01 Installation Page 2-3
Revision A January 15, 2015
