Lynx NGT-9000s
Installation Manual
1.11.4 Traffic Displays
Traffic information is output to a compatible traffic display from the unit using an ARINC 735B interface
format. Possible traffic output format selections include Standard TCAS Intruder File (STIF or TIF) and
Display Traffic Information File (DTIF). The unit allows installed configuration selection of STIF, DTIF,
or both formats of output data via the ARINC 429 bus to the traffic display. Displays not listed below can
still be found to be compatible for installation, but must meet the same specifications.
Table 1-22: Traffic Displays
MANUFACTURER MODEL SW VERSION
Garmin GNS 430W (Standard traffic only) 5.0 GPS SW / Version 5.10
Garmin G 500 (Standard traffic only)
GDU-620 Version 6.11
FPGA and I/O Version – 2.1
Garmin GTN 650 (Standard traffic only)
(2)
4.0 GPS / SW Version – 5.0
Garmin GMX 200 (Standard traffic only)
(1)
2.13
Garmin MX 20 (Standard traffic only)
(1)
Version – 5.7
Notes:
(1) For Installations using the MX 20 or GMX 200:
• Traffic may be displayed using the ARINC 429 interface (GMX 200 requires optional 429 card)
• The RS-422 interface for traffic is a future option.
(2) Installation using the GTN 650 as an external traffic display should note that the NGT-9000 Pilot-Initiated Self
Test, traffic test pattern is oriented to a heading of zero degrees. (I.e. if the aircraft is pointed a direction other
than True North, the traffic in the test pattern may be rotated relative to the difference between true heading and
0 degrees.)
1.11.5 Weather Display
Table 1-23: FIS-B WX Displays
MANUFACTURER MODEL SW VERSION
Garmin GMX 200
(1)
2.13
Notes:
(1) Traffic must be disabled if using the GMX 200 as a weather display.
1.11.6 WIFI Accessory
The Wifi accessory is also referred to as a “dongle”.
Table 1-24: RS-232 to WiFi Accessories
MANUFACTURER MODEL OR PART
NUMBER
Roving Network RN370M
L-3 Avionics Systems 9080-10024-01
0040-17001-01 General Information Page 1-31
Revision A January 15, 2015
