Lynx NGT-9000
Installation Manual
3.9.3 Live Data – ADS-B
1. From the Lynx MAT select ServiceZLive DataZADS-B. An example of this page is shown in
Figure 3-17.
2. Observe that both data fields are showing a count tally of received messages (A zero is a valid
number if the unit is not in range of a signal). If data is not being received do the following:
• The signal may be blocked; move the aircraft to an open environment or input a signal using
test equipment.
• Check the fault log (InfoZFault Log) for issues.
3. Check wiring or antenna for installation issues.
Figure 3-17: Lynx MAT – Live Data - GPS
0040-17001-01 Installation Checkout Page 3-21
Revision A January 15, 2015
