Lynx NGT-9000s
Installation Manual
[J1 connector] (Continued)
PIN 6
Signal Name:
ALT_IN_A2
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics:
+30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection:
See paragraph A.2.4
24 AWG wire
Comments:
PIN 7
Signal Name:
ALT_IN_A4
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics: +30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection: See paragraph A.2.4
24 AWG wire
Comments:
PIN 8
Signal Name:
ALT_IN_B1
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics: +30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection: See paragraph A.2.4
24 AWG wire
Comments:
PIN 9
Signal Name:
ALT_IN_B2
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics:
+30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection:
See paragraph A.2.4
24 AWG wire
Comments:
Page A-10 Appendix A 0040-17001-01
January 15, 2015 Revision A
