Lynx NGT-9000 User Manual

Lynx NGT-9000s
Installation Manual
[J1 connector] (Continued)
PIN 14
Signal Name:
ALT_IN_D2
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics:
+30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection:
Not Connected
Comments:
This input used for high altitude aircraft.
PIN 15
Signal Name:
ALT_IN_D4
Signal Function:
Gilham Altitude Encoder
Electrical Characteristics:
+30 V input max, < 1 mA sourced per line
Frequency: 20 Hz, Source Z: > 10 kΩ per line
Max Capacitance: < 20 pF per line
Connection:
See paragraph A.2.4
24 AWG wire
Comments:
PIN 16
Signal Name:
GROUND
Signal Function:
Signal Ground
Electrical Characteristics:
---
Connection:
Ground
Comments:
PIN 17
Signal Name:
CM SDA
Signal Function:
SDA Serial Data
Electrical Characteristics:
See paragraph A.2.11
Connection:
Detachable Configuration Module – Yellow wire
Comments:
PIN 18
Signal Name:
CM SCL
Signal Function:
SCL Serial Clock
Electrical Characteristics:
See paragraph A.2.11
Connection:
Detachable Configuration Module – green wire
Comments:
Page A-12 Appendix A 0040-17001-01
January 15, 2015 Revision A
