Lynx NGT-9000s
Installation Manual
[J1 connector] (Continued)
PIN 24
Signal Name:
DISC_OUT4 (Discrete Output No. 4)
Signal Function:
TIS-B Not in coverage
Electrical Characteristics:
GND/Open (GND active)
Ground State < 3.0Vdc when sinking 250mA. Open State
has an impedance of >100K ohms to ground for voltages
applied to the output of 0.0 to 36.0Vdc.
Connection:
Indicator Lamp
24 AWG wire
Comments:
See paragraph A.2.10.
PIN 25
Signal Name:
DISC_OUT5 (Discrete Output No. 5)
Signal Function:
Reserved (Audio Mute Command)
Electrical Characteristics:
GND/Open (GND active)
Ground State < 3.0Vdc when sinking 250mA. Open State
has an impedance of >100K ohms to ground for voltages
applied to the output of 0.0 to 36.0Vdc.
Connection:
No Connection
Comments:
See paragraph A.2.10.
PIN 26
Signal Name:
DISC_OUT6 (Discrete Output No. 6)
Signal Function:
ADS-B Fail Indicator
Electrical Characteristics:
GND/Open (GND active)
Ground State < 3.0Vdc when sinking 250mA. Open State
has an impedance of >100K ohms to ground for voltages
applied to the output of 0.0 to 36.0Vdc.
Connection: Indicator Lamp
24 AWG wire
Comments:
See paragraph A.2.10.
PIN 27
Signal Name:
DISC_IN1 (Discrete Input No. 1)
Signal Function:
IDENT
Electrical Characteristics: GND/Open (GND active)
Ground State ≤ 3.5Vdc, Open State ≥ 18Vdc
Connection:
Momentary Switch
24 AWG wire
Comments:
See paragraph A.2.9.
Page A-14 Appendix A 0040-17001-01
January 15, 2015 Revision A
