26
Back Button
When in any of the keyboard’s available editing modes, this button will send a message to go
back to a previous menu. When not in any of the edit modes, this button will send a separate
MIDI, Mackie or Mackie/HUI message in DAW mode. When in PRESET mode, this button will
send a separate user editable MIDI message when preset 1-16 is selected.
When SHIFT is pressed and held with this button it will delete the currently selected letter
when saving a User Preset Name, or User DAW Name.
Encoder and Encoder Button
When in any of the keyboard’s available editing modes this Encoder is used for scrolling
through selections when turned left and right and will enter when pressed. When in DAW
Mode this Encoder will send separate Up/Down or Left/Right messages (depending on the
DAW), and Enter messages. In Preset mode this Encoder will either send the same message
as the DAW Encoder assignment or send Program or CC messages.
When NOTE REPEAT is active the Encoder will be used for selecting NOTE REPEAT and
ARP time division settings.
Mode LEDs
These LEDs will change depending on what the current keyboard mode is. In Preset and DAW
mode, the fader buttons silkscreened options will always be available for selection. In DAW
mode, the fader buttons silkscreened options will be available for selection, as well as track
Record (Record arm), Select, Mute, and Solo. In Preset mode, the fader buttons silkscreened
options will be available for selection, as well as user editable MIDI messages.
DAW Mode
• Off/No LEDs: Fader Buttons will activate the following options:
o ARP On/Off, ARP Edit Enter/Exit
o ARP Latch On/Off
o Smart Chord On/Off, Chord Edit Enter/Exit
o Smart Scale On/Off, Scales Edit Enter/Exit
o 1/4, 1/4T – Timing selection for the ARP and Note Repeat messages.
o 1/8, 1/8T – Timing selection for the ARP and Note Repeat messages.
o 1/16, 1/16T – Timing selection for the ARP and Note Repeat messages.
o 1/32, 1/32T – Timing selection for the ARP and Note Repeat messages.
• Rec/Red LED: Fader Buttons will activate Record Arm MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
• Select/Green LED: Fader Buttons will activate Track Select MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
• Mute/Blue LED: Fader Buttons will activate Mute MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
• Solo/Yellow LED: Fader Buttons will activate Solo MIDI, Mackie, or Mackie/HUI
messages for the associated button’s current channel in your DAW.
