33
Keybed
To edit your Oxygen Pro’s Zone and Aftertouch assignments when in Preset Edit Mode, press
a key on the keyboard. You can scroll through the available parameter values using the
Encoder. Select what parameter you would like to edit by pressing the Encoder.
Zones:
The keybed (the piano keys) on your Oxygen Pro can be divided into 1–4 “zones.” When
zones are active each zone can send its controls’ MIDI messages over its own MIDI channel.
You can assign the parameters for the keybed/zones in Preset Edit mode only.
Tip: This feature is great for dividing your keyboard between different virtual instruments or
synthesizers. For example, you can create two zones, each using a different MIDI channel, and
play and control two virtual instruments simultaneously—one with each half of the keys.
• Enabled: Turns the associated function on or off.
• First: The zone’s lowest key will correspond with this note.
• Last: The zone’s highest key will correspond with this note.
Note: When the First or Last Note is selected in Zone Edit mode you can press a key on
the keybed to enter the First or Last note. The enables you to make a quick selection and
avoid using the Encoder to make a selection.
• Octave: The zone’s keys will send their notes using this octave shift (from their original
position on the keybed).
Note: The zone octave and transposition are independent from the keyboard’s overall
octave and transposition, but all of these affect the note a key sends out.
• Transpose: The zone’s keys will send their notes using this transposition (from their
original position on the keybed).
Note: The zone octave and transposition are independent from the keyboard’s overall
octave and transposition, but all of these affect the note a key sends out.
• Program: The zone will send this program number when you press a key in it.
• MSB: The zone will send this Bank MSB (Most Significant Byte) number when you press a
key in it.
• LSB: The zone will send this Bank LSB (Least Significant Byte) number when you press a
key in it.
• Chan: The zone will send its messages over this channel. Select the global channel
(Global) or a specific channel (Channel 1–16).
Note: Any other controls whose Chan settings are set to this zone will send their messages
using this channel, as well.
Aftertouch:
• Chan: The aftertouch will send its messages over this channel. Select the global channel
(Global), a specific channel (Channel 1–16), a zone (Zone 1–4), or all channels (Omni).
• Min: The lowest note played in the range will correspond with this value.
• Max: The highest note played in the range will correspond with this value.
