66
Editable Preset Controls
Pitch Wheel
To edit the Pitch Wheel control when in Preset Edit Mode, move the Pitch Wheel. You can
scroll through the available parameter values using the Encoder. Select what parameter you
would like to edit by pressing the Encoder.
Channel: The Pitch Wheel will send its messages over this channel. Select the global channel
(Global), a specific channel (Channel 1–16), a zone (Zone 1–4), or all channels (Omni).
Available Values: Global, 1-16, Zone 1-4, Omni
Minimum Value: The wheel’s minimum position will correspond with this value. You can
reverse the wheel’s polarity by making this value larger than the Max value.
Available Values: 0-127
Maximum Value: The wheel’s maximum position will correspond with this value. You can
reverse the wheel’s polarity by making this value smaller than the Min value.
Available Values: 0-127
Modulation Wheel
To edit the Modulation Wheel control when in Preset Edit Mode, move the Modulation Wheel.
You can scroll through the available parameter values using the Encoder. Select what
parameter you would like to edit by pressing the Encoder.
Channel: The Mod Wheel will send its messages over this channel. Select the global channel
(Global), a specific channel (Channel 1–16), a zone (Zone 1–4), or all channels (Omni).
Available Values: Global, 1-16, Zone 1-4, Omni
CC: The Mod wheel will send its MIDI messages using this CC number.
Available Values: 0-127
Minimum Value: The wheel’s minimum position will correspond with this value. You can
reverse the wheel’s polarity by making this value larger than the Max value.
Available Values: 0-127
Maximum Value: The wheel’s maximum position will correspond with this value. You can
reverse the wheel’s polarity by making this value smaller than the Min value.
Available Values: 0-127
