MacDon D60 - Double Windrow Attachment; Draper Extension Kit; Swath Forming Rods (Center Delivery)

169441 252 Revision D
5.4.3 Double Windrow Attachment
The Double Windrow Attachment (DWA) can be attached to an M Series Self-Propelled Windrower to enable double-
windrowing with a hay conditioner.
1005249
Figure 5.12: Double Windrow Attachment (DWA)
The DWA
7
lays up to 18.3 m (60 ft.) of crop in a single windrow
which is ideal for large forage harvesters. It is designed to
mount only on SP windrowers equipped with an HC10
Conditioner
8
.
5.4.4 Draper Extension Kit
The draper extension kit increases the inboard length of each deck up to 250 mm (10 in.), which narrows the header
opening and decreases windrow width when cutting light/thin crops.
The kit includes roller support extensions, a draper repair kit, all necessary hardware, and installation instructions.
MD #B5407
9
5.4.5 Swath Forming Rods (Center Delivery)
Swath forming rods form windrows so the heads are in the center and protected from shatter. Swath forming rods are
mainly used for grass seed cutting applications.
1004321
Figure 5.13: Swath Forming Rods
Installation and adjustment instructions are included with
the kit.
MD #B4803
OPTIONS AND ATTACHMENTS
7. This option is not compatible with the M105 SP Windrower.
8. This option is not for use with the M205 or M105 SP Windrower.
9. Not for use with Double Draper Drive (DDD).
