Shifting Decks Hydraulically
The hydraulic deck shift feature allows you to select center, left, or right delivery from the windrower cab. It is only
available on 7.6–12.2 m (25–40 ft.) D60 Draper Headers.
Refer to your windrower operator’s manual for identification and operation of the deck shift control.
To lay a double windrow, do the following:
1004691
A
B
Figure 3.77: Double Windrowing
1. Position the decks at the left end of header to deliver crop
from right end (A) for the first round.
2. To deliver crop from the left end (B) of the header, use the
deck shift control in the windrower to shift the decks to the
right end of the header.
3. Complete the second round to lay a double windrow.
4. Repeat above steps to lay additional double windrow.
NOTE:
The end delivery opening is designed to give adequate
clearance between the first windrow and the standing crop,
and optimum space between the two windrows.
Shifting Decks Manually
Both decks can be shifted manually, and can be positioned to deliver the crop from the right or left end and from the
center.
DANGER
To prevent bodily injury or death from the unexpected start-up of the machine, always stop the engine and remove the
key from the ignition before making adjustments to the machine.
