MacDon D60 - Page 272

169441 260 Revision D
Problem Solution Refer to
Cutting tough crops with standard
torque (19-tooth) reel drive sprocket
Replace with high torque (10-tooth) or
14-tooth reel drive sprocket
Optional Reel Drive Sprockets – D60,
page 50
Symptom: Plastic Fingers Cut at Tip
Insufficient reel to cutterbar clearance Increase clearance
4.10.1 Reel Clearance to Cutterbar,
page 197
Symptom: Plastic Fingers Bent Rearward at Tip
Reel digging into ground with reel
speed slower than ground speed
Raise header
3.12.1 Cutting Height, page 43
Reel digging into ground with reel
speed slower than ground speed
Decrease header tilt
Controlling Header Angle, page 49
Reel digging into ground with reel
speed slower than ground speed
Move reel aft
3.12.9 Reel Fore-Aft Position, page 55
Symptom: Plastic Fingers Bent Forward at Tip (Opposite of Above)
Reel digging into ground with reel
speed faster than ground speed
Raise header
3.12.1 Cutting Height, page 43
Reel digging into ground with reel
speed faster than ground speed
Decrease header tilt
Controlling Header Angle, page 49
Reel digging into ground with reel
speed faster than ground speed
Move reel aft
3.12.9 Reel Fore-Aft Position, page 55
Symptom: Plastic Fingers Bent Close to Tine Tube
Excessive plugging at cutterbar with
wads of crop accumulating at
cutterbar while maintaining reel
operation
Correct plugging/cutting issues
3.19 Unplugging Cutterbar, page 91
Excessive plugging at cutterbar with
wads of crop accumulating at
cutterbar while maintaining reel
operation
Stop reel before plugging becomes
excessive
—
TROUBLESHOOTING
