5-1 ENFASET MOTOR
KAPITEL 5 - ELDIAGRAM
Komponent Beskrivelse og funktion
SA1
(1) (2)
(0)
(1) (2)
Hastighedsomskifter
Start
Standsning
Ombytning
L1, L2 Linie
C1 Condensatore
M1 Enfaset motor
DA
285
