110
BA052301-
en
11.2.4
Delete Profile
A profile can be deleted
via the menu
point DELETE PR
OFILE .
There is no security inquir
y when deleting and
there is no p
ossibility to restore the
profile!
11.3
Backup/Resto
re Database
11.3.1
Backup Database
1
Enter the file name
and if necessary, sele
ct
a path.
2
Confirm with <STO
RE>
The database backup file is
stored on the h
ard dis
k under
C:
\MAH
A\*Dyno Mod
el*
\Backup\
...
11.3.2
Restore Database
1
Select a database
backup file.
2
Confirm with <O
PEN>
The database backup file
is opened from
C:
\MAH
A\*D
yno Mod
el*\Backup\...
as
standard path.
109
111
