MAHA LPS 3000 User Manual

BA052301-en 65
9 Measurements
9.1 Load Simulation
The Load simulation menu enables the user to preselect various load conditions which, for ex-
ample, make possible targeted engine diagnosis or determination of the climbing performance
of a vehicle. After selecting the menu item, the following screen appears:
• Const. traction
• Const. speed
• Road load simulation
• Const. Engine RPM
• Standstill
9.1.1 Identical Functions
Button Description
LEVEL 1
Target
value +/-
F5
• The target value can be changed and confirmed during the
measurement.
Change the value with the +/- keys or with the remote control scroll
key. If the desired value is set, it is confirmed with the <F5> key.
Target
value OK
F5
Start
F6
• The graphic recording of the measurement is started or stopped.
Stop
F6
Driving cycle
F7
• A driving cycle from the database can be selected.
Evaluate
F8
• The measurement evaluation is displayed.
LEVEL 2
Store
F5
• The measurement is stored.
Reset
F6
• The graphic recording of the measurement is reset to zero.
Profile
F7
• A display profile can be selected from the database.
Reset travel
distance
F8
• The travel distance measurement is reset to zero.
LEVEL 3
Enter target
value
• Use this button to change the current target value (e.g. Speed 50 km/h)
without having to quit the program.
