MAHA LPS 3000 User Manual

BA052301-en 21
2.5 Description of the Interface Box
The Interface Box records engine RPM, environmental data, OBD data, temperature, pressure
and analog signals. This is done via modules. A maximum of 4 modules can be installed in the
interface box.
Additional modules can be installed in a second interface box which is connected parallel and, if
desired, adapted to customer requirements.
As standard equipment, the interface box 1 has an RPM and an environmental module.
Dimensions (H x W x L) .......................................................................... approx. 120 x 170 x 160 mm
Weight ............................................................................................................................. approx. 1.0 kg
DRZ PTH OBD P2T2
A
B
D
C
H
E
F
I
M
L
K
J
G
