BA052301-en 19
2.3 Main Switch
• Main switch in position 0: Power supply OFF
• Main switch in position 1: Power supply ON
• When in position 0, the main switch can be protected against tampering
by means of a padlock.
Use this key to activate the lifting bar. It can then be operated with the
cursor keys.
Selection of a menu item
(In combination with the function key F5 and the cursor keys target
values can be increased or decreased in some menus.)
Deleting the character before the cursor position
Discarding of inputs
Switch over to letter mode
Connection for Pedal force sensor
In some menus special functions can be opened. The key assign-
ments vary in the different menus. Four boxes with diverse functions
are located on the lower screen edge in these menus. These options
are selected with the function keys F5 to F8 on the remote control. If
the button bar has further levels, these can be displayed using the
cursor keys.
Use this key to activate the load simulator. It can then be operated
with the cursor keys.
Use this key to activate the roller set adjustment. It can then be
operated with the cursor keys.
The functions of the program can also be selected via the remote control. The remote control
can be operated directly from the vehicle.
The signal is transmitted by radio. The receiving antenna for the signal is located in the desk.
Should several dynos each with its own remote control be operated in one room, the remote
controls must be set to different channels.
