14000 OPERATOR MANUAL SETUP AND INSTALLATION
Remove Crane from Trailer
See Figure 4-8 for the following procedure.
1. Untie carbody (4) from trailer (5).
2. Position each carbody jack (6) as follows:
a. Remove hitch pin (7, View E).
b. Swing jack out (View F).
c. Install hitch pin (7, View F).
3. Remove jack pads (8, View D) from storage and connect
to jack rods with U-shaped pins (View F).
4. Perform pre-start checks and start engine.
NOTE: It is normal for faults (engine and hydraulic) to
come on when the engine is started.
The faults should go off as engine oil pressure and
hydraulic oil temperature rise to normal. If faults do
not go off soon after start-up, determine fault, stop
engine, and correct cause (see Main Display
instructions in Section 3).
5. Using controls (11, View A) on front of carbody, extend
carbody jacks fully to raise crane off trailer.
NOTE: Level (12) is provided near controls.
6. Slowly pull trailer out from under crane.
7. Retract jacks (keep crane level) until carbody is
approximately 2 ft (0,6 m) above ground.
WARNING
Moving Part Hazard!
Avoid serious crushing injury:
• Warn all personnel to stand clear of jacks
Tipping Hazard!
Avoid tipping crane over:
• Keep crane level while jacking
OPERATING NOTE
360° swing is permitted when crane is on jacks with
gantry and mast in transport position.
