Manitowoc Published 03-29-17, Control # 064-23 v2 4-53
14000 OPERATOR MANUAL SETUP AND INSTALLATION
4
Remove Counterweight
Remove Crane Counterweight
NOTE: If not already done, select Liftcrane Mast
Capacities Chart in configuration screen of RCL
display.
The mast and gantry controls will not operate
properly and the mast operating limits will remain
off until the proper capacity chart is selected.
See Figure 4-24
for the following procedure.
1. Removal will be easier if rear of crane is slightly higher
than front of crane — travel rear of crawlers onto
blocking approximately 1 in (25 mm) high.
2. Remove step from carbody counterweight under crane
counterweight.
3. Perform following steps in operator’s cab:
a. Turn off boom hoist (Drum 4) park switch.
b. Turn on setup remote control in function mode
screen of main display.
c. If not already done, fully raise mast arms (2, View C)
using switch in operator’s.
4. Lower mast (boom down) to a minimum of 150°.
Mast must be positioned at this angle so it does not
contact mast arms when gantry is lowered.
Otherwise, damage will occur.
5. Fully extend gantry cylinders (5, View B) with remote
control until rod ends are snug against gantry.
6. Remove pins (6, View B) from storage and pin cylinder
rods ends to gantry.
7. Disconnect stabilizer rods:
a. Loosen lock nuts (7, View D) and flange nuts (8).
b. Pin stabilizer rods (10, View E) in shipping position
with snap pins (11).
8. Remove cotter pins and disengage backhitch pins (12,
View B) with remote control. Keep pins disengaged until
gantry is lowered (step 9
).
Visually check that both backhitch pins are fully
disengaged.
DANGER
Tipping Hazard!
Prevent crane from tipping:
• Remove crane counterweight before removing
carbody counterweight
Moving Part/Crush Hazard!
Avoid being crushed by moving parts:
• Do not stand on counterweight while it is being
lowered
• Never go under counterweight while it is being
lowered
Falling Mast Hazard!
Prevent mast from falling:
• Do not raise mast to vertical until mast arms are fully
raised. Mast will fall over backwards if raised to
vertical when arms are down
WARNING
Falling Counterweight Hazard!
Prevent counterweight from falling off crane:
• Do not attempt to lower counterweight until stabilizer
rods are disconnected in step 7.
Structural damage will occur, possibly causing tray to
tip and counterweight boxes to fall off tray
