OPERATING CONTROLS AND PROCEDURES 14000 OPERATOR MANUAL
3-10
Published 03-29-17, Control # 064-23
CAB WINDOW OPERATION
See Figure 3-2, in the following procedures.
Opening Windows for Ventilation
Past Production Cab
The right-side and rear windows can be opened for
ventilation as shown in Views A and D.
For non-European cabs only, the roof window can be opened
for ventilation as shown in View C.
Current Production Cab
The right-side and rear windows can be opened for
ventilation as shown in Views B and E.
For non-European cabs only, the roof window can be opened
for ventilation in the same manner as the right-side window
(View B).
NOTE: European code requires a roof window that cannot
be opened.
Exiting Cab in Emergency
If you cannot exit the cab through the sliding door, proceed
as follows:
Past Production Cab Only
Remove knobs (5) at top of rear window, open latches (4) at
bottom of rear window, push rear window out, and exit cab
through window opening.
Current Production Cab Only
While seated in the cab seat, “kick out” the front window and
exit the cab through the opening. The front window is
attached to the cab frame with offset rubber molding that
allows the window to be “kicked out”.
OPERATING CONTROLS
General
The purpose of the following instructions is to familiarize
qualified personnel with the location and function of the
operating controls on this crane. This section also contains
safety information and a description of operation for each
crane function.
Depending on the options your crane is equipped with, some
controls identified in this section will not apply.
WARNING
To prevent death or serious personal injury:
• Read and thoroughly understand instructions in this
section, in Section 2, and in Capacity Chart Manual.
• Contact your Manitowoc dealer for assistance if you
do not clearly understand any operating procedure.
