14000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Squeeze Latch
and Pull to Open
Unlatch and Rotate
Out to Open
Rotate Handle
to Unlatch
Push Up
to Open
FIGURE 3-2
P2391a
View D
Past Production (2 places)
View C
Past Production
3
Squeeze Latch
and Pull to Open
5
1
View A
Past Production
View B
Current Production
2
P2389a
P2390aP2391b P2515
4
Item Description
1 Latch (right-side window)
2 Latch (right-side and roof window)
3 Latch (roof window)
4 Latch (rear window)
5Knob
Unlatch and Rotate
Out to Open
View E
Current Production
4
P2389b
