Manitowoc 14000 User Manual

Reference Only
SETUP AND INSTALLATION 14000 OPERATOR MANUAL
4-54
Published 03-29-17, Control # 064-23 v2
12
13
View G
View H
FIGURE 4-24 continued
11
14COM4130ab
14COM4130ad
14COM4130aj
Circled Numbers Correspond to
REMOVE COUNTERWEIGHT
Procedure
Item Description Item Description
1 Mast 10 Stabilizer Rod (2)
2 Mast Arm (2) 11 Snap Pin (2)
3 Assembly Block 12 Backhitch Pin (2)
4 Gantry 13 Tray with Counterweight Boxes
5 Gantry Cylinder (2) 14 Upper Handling Strap (8)
6 Pin with Cotter Pins (2) 15 Pin with Cotter Pin (4)
7 Lock Nut (2) 16 Lower Handling Strap (4)
8 Flange Nut (2) 17 Storage Link (2)
9 Bracket (2)
Numbers in parentheses equal quantity
View F
16
15
14
16
Stored
13
4
6
12
5
17
9
10
12
9
12
