SETUP AND INSTALLATION 14000 OPERATOR MANUAL
4-32
Published 03-29-17, Control # 064-23 v2
Figure 4-18 continued
View G
5
Item Description
1Tray
2Center Box
3 Side Box
4 Gantry
5 Upper Handling Strap (8)
6Pin with Cotter Pin (4)
7 Lower Handling Strap (4)
8 Storage Link (2)
9 Gantry Cylinder (2)
10 Backhitch (2)
11 Backhitch Pin with Cotter Pin (2)
12 Lower Holes
13 Upper Holes
14 Pin with Cotter Pins (2)
15 Alignment Pin (3)
16 See Next Page
17 Mast
18 Mast Arm (2)
19 Assembly Block
Number in parentheses equal quantity
14COM4130aa
14COM4130ab
14COM4130ad
View F
18
4
8
9
2
Circled Numbers Correspond to
INSTALL COUNTERWEIGHT
Procedure
View D
1
4
11 and 12
3
2
(not shown)
7
6
5
8
9
10
7
(stored)
15
1
View E
(crane side of tray)
P2477
3
17
6
See
View D
13
17
19
18
7
7
19
14
150°
Minimum
126°
