View B
CURRENT PRODUCTION
2
Stored
1
On Trailer
4
7
3
14COM4138
5
Item Description
1 Boom Butt
2 Wire Rope Guide
3
Chain Sling (4-leg)
1
4 Assembly Block
5 Lifting Lug (front)(2)
6 Owner-Furnished Slings (2)
7 Lifting Lug (rear)(2)
8 Lifting Lug (front)(2)
9 Lifting Lug (middle)(2)
10 Lifting Lug (rear)(2)
Numbers in parentheses equal quantity
1
Same Chain Sling Used for Crawler Handling
4
3
2
Stored
10
9
FIGURE 4-19
Approximate Sling Length
2 ft 11 in (0,89 m) without Drum in Butt
3 ft 10 in (1,17 m) with Drum in Butt
6
View A
PAST PRODUCTION
14COM4137a
14COM4196
1
B
A
8
Optional Drum
in Butt
