Item Dimension
1 32 ft 3 in (9,83 m)
2a 18 ft 8 in (5,69 m) Overall Length
2b 19 ft 4 in (5,90 m) Counterweight Tail Swing
3 27 ft 3 in (8,30 m)
4 13 ft 8 in (4,16 m)
5 4 ft 0 in (1,22 m)
6a 27 ft 8 in (8,43 m) Overall Length
6b 27 ft 9 in (8,46 m) Mast Tail Swing
7 4 ft 6 in (1,37 m)
8 11 ft 7 in (3,53 m)
9 8 ft 0 in (2,44 m)
10a 11 ft 3 in (3,43 m) Top of Cab Rails
10b 11 ft 9 in (3,58 m) Top of Warning Light
11 40 ft 10 in (12,45 m)
12 0 ft 10 in (0,30 m) (bottom of step to ground)
13 32 ft 6 in (9,91 m) Overall Length
14 15 ft 7 in (4,75 m) with 20 in (508 mm) Wide Catwalk
14 15 ft 11 in (4,85 m) with 24 in (610 mm) Wide Catwalk
15 12 ft 11 in (3,94 m)
16 3 ft 9 in (1,15 m)
17 1 ft 1 in (0,33 m) (bottom of carbody to ground)
18 22 ft 3 in (6,79 m)
19 25 ft 4 in (7,73 m)
20 4 ft 0 in (1,22 m)
21a 11 ft 0 in (3,35 m) Series 1
21b 12 ft 11 in (3,94 m) Series 2
21c 13 ft 6 in (4,10 m) Series 3
FIGURE 1-3 continued
