Manitowoc Published 03-29-17, Control # 064-23 v2 4-49
14000 OPERATOR MANUAL SETUP AND INSTALLATION
10. Boom down until hooked connectors (10, View M) in
boom butt disengage fixed pins (11) in insert (12).
11. Travel away from boom.
12. Lower boom butt onto blocking (View L).
13. Lower mast to approximately 172°.
14. Disconnect pendants (7, View L) from lifting lugs on
boom butt.
15. Pin pendants (7, View L) to storage lugs (8) on mast (2).
16. Position trailer as shown in View J.
17. Reeve wire rope from rear drum through center sheave
in mast point and sheave in assembly block (see View B,
Figure 4-11
).
18. Anchor wire rope to socket and wedge (6, View K) (see
Wire Rope Installation on Page 98
for instructions) and
connect socket and wedge to lug on mast.
19. Raise mast to lift assembly block (3) off trailer and
position mast in operating range.
20. Connect 4-leg chain sling to assembly block.
DANGER
Falling Mast Hazard!
Prevent mast from falling:
• Do not use limit bypass to lower mast below 172°.
Mast will fall suddenly
CAUTION
Avoid mast and wire rope damage:
• Do not lower mast onto boom butt wire rope guide.
Lacings can be damaged
CAUTION
Wire Rope Damage!
Prevent damage to wire rope and mast:
• Do not operate rear load drum until wire rope is clear
of lacing in mast (View A)(at approximately 145°)
Legend for FIGURE 4-22 continued
Item Description Item Description
1 Boom Butt 7 Pendant
2 Mast 8 Storage Lug
3 Assembly Block 9 Lifting Lug
4 Chain Sling (not shown) 10 Hooked Connector
5 Trailer 11 Fixed Pin
6 Socket and Wedge 12 Insert
