Manitowoc 14000 User Manual

Reference Only
SETUP AND INSTALLATION 14000 OPERATOR MANUAL
4-92
Published 03-29-17, Control # 064-23 v2
FIGURE 4-43
Lift Jib Point to Assist
in Pinning Backstay
Pendants
From
Assist
Crane
View C
View A
5
° Offset
15
° Offset
View D
P548a
J2
8
25° Offset
8
11
9
P1
View E
P1, P2, or P3
11
8
8
11
10
Item Description
J1 Jib Butt
J2 Jib Top
P1 Basic Jib Pendant — 30 ft 9 in (9.37 m)
P2 Jib Pendant — 19 ft 0 in (5.79 m)
P3 Jib Pendant — 9 ft 6 in (2.89 m)
1 Pin with Cotter Pin
2Jib Strut
3 Strut Link
4 Pin with Cotter Pin
5 Backstay Link
6 Upper Spreader
7 Lower Spreader
8 Backstay Pendant with Pin — 44 ft 7 in (13,6 m)
9
15
° Offset Link with Pin — 28 in (711 mm)
10
25
° Offset Pendant with Pin — 4 ft 8 in (1,4 m)
11 Backstay Link with Pin
12 Backstay Lug
13 Weight Ball
2
2
13
J2J1
12
1
1
3
5
6
7
4
4
2
14COM4167
14COM4168
14COM4169
8
