SETUP AND INSTALLATION 14000 OPERATOR MANUAL
4-94
Published 03-29-17, Control # 064-23 v2
16
Stored
FIGURE 4-44
View C
View E
P550
P552
3
Stored
17
Engaged
16
Installed
17
Disengaged
View B
P546
Item Description
1 Jib Stop Assembly
2Jib Strut
3Pin with Snap Pin
4 Boom Top
5Pin with Cotter Pin
6 Offset Pin with Snap Pins
7 Inner Tube
8Link
9 Control Cable Extension
10 Sheave
11 Control Cable (from Jib Stop)
12 Shackle
13 Control Cable (from Winch)
14 Winch
15 Pawl Lever
16 Safety Pin
17 Jib Stop Pin
12
9
15° Offset
Hole
25
° Offset
Hole
View A
1
4
5
6
5
° Offset Hole
8
12
11
9
7
2
13
10
14COM4170
14COM4166
View D
P551
14
15
