ELECTRIC SYSTEM 18000 SERIVCE/MAINTENANCE MANUAL
3-16
Published 12-05-17, Control # 035-23
54-H DO-14 Drum 6 Pump Control – Lower See Table 3-3 for Values CAN38-2-32
54-K Ground Drum 4A Pump Control – Lower Ground
54-L Ground Drum 4A Pump Control – Raise Ground
54-M DO-17 Drum 4A Pump Control –Raise See Table 3-3
for Values CAN38-3-1
54-N Ground Pump Drive Cooler 1 Ground
54-P DO-16 Pump Drive Cooler 1 0 Volts Off; 24 Volts On CAN38-2-128
54-S DO-18 Drum 4A Pump Control – Lower See Table 3-3
for Values CAN38-3-2
54-T Ground Drum 4B Pump Control – Raise Ground
54-U DO-19 Drum 4B Pump Control – Raise See Table 3-3
for Values CAN38-3-4
54-V Ground Drum 4B Pump Control – Lower Ground
54-W DO-20 Drum 4B Pump Control – Lower See Table 3-3
for Values CAN38-3-8
54-X Ground Swing 2 (optional) Pump Control – Left Ground
54-Z DO-21 Swing 2 (optional) Pump Control – Left See Table 3-3
for Values CAN38-3-16
54-a Ground Swing 2 (optional) Pump Control – Right Ground
54-b DO-22 Swing 2 (optional) Pump Control – Right SeeTable 3-3
for Values CAN38-3-32
54-c Ground Pump Drive Cooler 2 Ground
54-d DO-23 Pump Drive Cooler 2 0 Volts Off; 24 Volts On CAN38-3-64
54-e Ground Accessory System Proportional Solenoid Ground
54-f DO-24 Accessory System Proportional Solenoid 0 Volts Off; 24 Volts On CAN38-3-128
54-g Ground Jumper to Node Select 4 Ground
54-m NS-4 Node Select Jumper to Ground 0 Volts (With Jumper)
J6 Receptacle – Limits
56-A Ground Drum 6 Pressure Sender Ground
56-B DO-7 Drum 6 Pressure Sender 0 Volts Off; 24 Volts On CAN38-1-64
56-C Ground Drum 4 Pressure Sender Ground
56-D DO-8 Drum 4 Pressure Sender 0 Volts Off; 24 Volts On CAN38-1-128
56-E Ground Maximum Boom Angle Limit Switch Ground
56-F DO-9 Pump Case Heat Control 0 Volts Off; 24 Volts On CAN38-2-1
56-G Ground Swing/Travel Alarm Ground
56-H DO-10 Swing/Travel Alarm 0 Volts Off; 24 Volts On CAN38-2-2
56-J DI-8 Maximum Boom Angle Limit Switch 0 Volts Off; 24 Volts On CAN69-1-128
56-N NS-4 Node Select 4 Jumper to Ground 0 Volts (With Jumper)
56-R 24 Volts Maximum Boom Angle Limit Switch 24 Volts
56-U Ground Jumper to Node Select 4 0 Volts (With Jumper)
56-V 5 Volts Drum 4 Motor Speed Sensor 5 Volts DC
56-W Ground Pump Case Heat Control Ground
56-a AI-9 Drum 6 Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN26-2
1
56-b AI-10 Drum 4 Pressure Sender
1 Volt at 0 psi;
5 Volts at 7,500 psi
CAN26-4
1
56-j Ground Drum 4 Motor Speed Sensor Ground
Can ID. No.
Function
Type
Description Test Voltage Packet No.
