18000 SERIVCE/MAINTENANCE MANUAL ELECTRIC SYSTEM
3
56-n ENC1A Drum 4 Motor Speed Sensor
1.2 or 3.2 Volt Not Moving;
2.2 Volts Moving
CAN68-2
1
56-p ENC1B Drum 4 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN68-2
2
1
– Lower four bits are the most significant bit of the analog value.
2
– The number in the indicated bank should increase with device rotation and decrease with rotation in opposite direction.
Can ID. No.
Function
Type
Description Test Voltage Packet No.
