Maintenance work on the carrier
7.4 Fuel system
07.12.2017
Maintenance manual 3 302 649 en 7 - 27
GMK4090
7.4 Fuel system
This section describes the maintenance work
for the standard fuel system with two con-
nected fuel tanks, (1) and (2), which may only
be filled with a single type of fuel.
For additional equipment with a dual tank
system, the fuel tanks (1) and (2) are separate
and are filled with different types of fuel;
à Operating manual.
• Obtain information from
Manitowoc Crane Care on the additional fuel
filter required for the dual tank system.
The following elements are installed as
standard in the carrier fuel line:
1 Fuel filter 1 (large)
2 Fuel filter 2 (small)
3 Fuel hand pump
