Manitowoc GROVE GMK4090 - Checking the Tyre Pressure

Maintenance work on the carrier
7.10 Wheels
7 - 68 3 302 649 en Maintenance manual
GMK4090
07.12.2017
7.10.2 Checking the tyre pressure
• Check the tyre pressure using the following table.
W
S
Risk of damage to the tyres
The air pressure increases when the tyres become hot during driving.
Never release the increased air pressure of tyres at operating temperature.
Always check the tyre pressure in on-road driving mode with cold tyres.
Tyres Air pressure in bar (psi)
with cold tyres
14.00 R 25
385/95 R25
9,0 (131)
16.00 R 25
445/95 R25
9,0 (131)
20.50 R 25
525/80 R 25
7,0 (102)
