Maintenance work on the carrier
7.11 Vehicle brake
07.12.2017
Maintenance manual 3 302 649 en 7 - 75
GMK4090
7.11 Vehicle brake
7.11.1 Checking brake lining thickness
Spare parts
and tools
– Measuring tool for brake linings.
Prerequisites – The truck crane must be parked over an inspection pit.
– The truck crane must be raised on outriggers.
– The engine is not running and is secured against unauthorised use;
à p. 2 - 3.
– The parking brake must be released.
Safety
instructions
• Do not perform repair work on the vehicle brakes; à Maintenance
instructions
, p. 1 - 2.
• Perform only maintenance work; à Checking, p. 7 - 76.
s
Designation Quantity per
axle line
GROVE part no.
1. and 2nd axle line (duplex brake)
Brake shoe with brake lining 4 03322112
Spring 4 03322110
Brake drum 2 01925703
3. and 4th axle line (simplex brake)
Brake shoe with brake lining 4 03322121
Spring 4 02315393
Brake drum 2 01925703
G
Risk of accidents due to incorrect work on the vehicle brakes
Incorrect work on the vehicle brakes can lead to failure of the brakes caus-
ing severe accidents.
Incorrect work invalidates the operating licence of the truck crane and no
claims of liability for damage can then be accepted.
All repair work on the vehicle brakes may only be performed by
Manitowoc Crane Care or an authorised GROVE dealer or an authorised
specialist workshop with specially trained repair crew.
