Maintenance work on the carrier
7.16 Central lubrication system
07.12.2017
Maintenance manual 3 302 649 en 7 - 109
GMK4090
7.16 Central lubrication system
7.16.1 Checking the filling level
Grease, spare
parts, tools
– Filling pump from the tool set.
Prerequisites – The parking brake is engaged.
Checking the
filling level
• Check the level in the grease container (1).
The grease level must be close to the max.
mark and the green lamp (2) must light
(ready for operation).
If it is below the min. mark the grease level
is too low and the red lamp (3) will light.
If the level is too low
• Add more grease; à p. 7 - 110.
s
Lubricating
grease
Designation
acc. to
DIN 51502
Specifications
Classification
GROVE part no.
Grease KP - 1K - 50 DIN 51825 03233369
