Manitowoc GROVE GMK4090 Maintenance Manual

Maintenance work on the carrier
7.3 Engine
7 - 16 3 302 649 en Maintenance manual
GMK4090
07.12.2017
7.3.3 Checking the air filter
• Start the engine and observe the display.
• If the symbol (1) is displayed, you must change the air filter.
• Switch the engine off.
Spare parts
and tools
Prerequisites – The engine is not running and is secured against unauthorised use;
à p. 2 - 3.
Replace air filter
• Undo all the clamps (1) and remove
the cap (2).
• Change the main filter (3) and the back-up
filter (4).
• Replace the cap and secure it with all the
clamps.
D
Designation Quantity GROVE part no.
Main filter 1 04158601
Back-up filter 1 04158602
