Maintenance work on the carrier
7.8 Angle gear
7 - 52 3 302 649 en Maintenance manual
GMK4090
07.12.2017
7.8.3 Changing the oil and the oil filter
Oil, spare parts,
tools
– Connecting piece and hose (tool box); à p. 7 - 102.
– Receptacle, about 10 l (2.5 gal); à p. 2 - 4.
Prerequisites – The truck crane must be raised on outriggers or parked over an inspec-
tion pit.
– The engine is not running and is secured against unauthorised use;
à p. 2 - 3.
– The angle gear must be adequately cooled.
– The inspection opening and the interior space must be clean and free of
oil so that the fitter can work safely in the restricted space where the angle
gear is installed.
Gear oil
in litres (gal)
Designation
acc. to
DIN 51502
Specifications
Classification
GROVE part no.
7,2 (1,9)
for type A
8,6 (2,3)
for type B
MIL-L 2105 B
API-GL-5
Viscosity:
Hyp SHC 75-90
01373344
Designation Quantity GROVE part no.
Angle gear:
Gasket 30 x 36 Cu DIN 7603
1 00117151
Filter:
Filter
1 03135866
Packing set 1 04161645
Oil cooler:
Drain plug with gasket
1 03326356
